Siechem
UL 3470 RoHS
Wires & Cables
Application
Product Construction
Technical Data
www.siechem.com440
Catalogue
No
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction
Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG
nos. / mm
mm
kg/km
mm
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08 White - 09 Orange - 10 Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14 LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19 Purple - 20
Pink - 21
39
ü
Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü
Insulation : EBXL-XLPE
ü
Colour : As per customer order.
0
ü
Temperature Range : +150 C
ü
Voltage Rating : 150 V AC
For Electronic use : 300 V
24
22
20
18
16
18
16
0.25
0.25
0.25
0.25
0.25
0.25
0.25
1.32
1.48
1.64
1.88
2.21
1.72
1.99
3.53
4.98
6.61
9.97
14.90
9.43
14.16
44084XX
44083XX
44082XX
44081XX
44080XX
S44081XX
S44080XX
0
Siechem UL 3470 APC, EBXL-XLPE Insulated 150 C, 150 V AC Cable
87.6
55.4
34.8
21.8
13.7
21.4
13.5
7/0.193
7/0.254
10/0.254
16/0.254
26/0.254
1/1.024
1/1.291
Max.
Conductor
Resistance
0
at 20 C
Ω/km
Features
ü
Appliance wiring
ü
Internal wiring of meters, panels, electrical
and electronic equipment.
ü
Flame retardant
ü
Resistant to water, oil, acids, solvents
and fungus.
OHSAS
18001
ISO
9001
ISO
14001
