45 / 46
www.siechem.com
445
Catalogue
No
44
Siechem
UL 10531 RoHS
Wires & Cables
Application
Product Construction
Technical Data
Features
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction
Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG
nos. / mm
mm
kg/km
mm
0
ü
Temperature Range : +105 C
ü
Voltage Rating : 600 V AC,
750 V DC
ü
Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü
Insulation : PVC
ü
Colour : As per customer order.
S445 82 XX 18 1 / 1.024 1.18 3.4 18.56 21.4
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08 White - 09 Orange - 10 Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14 LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19 Purple - 20
Pink - 21
0
Siechem UL 10531 APC, PVC Insulated 105 C, 600 V AC Cable
Ω/km
Max.
Conductor
Resistance
0
at 20 C
ü
Appliance wiring
ü
Internal wiring of meters, panels, electrical
and electronic equipment.
ü
Flame retardant
ü
Resistant to water, oil, acids, solvents
and fungus.
OHSAS
18001
ISO
9001
ISO
14001
