Siechem
UL 1275 RoHS
Wires & Cables
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction
Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG
nos. / mm
mm
kg/km
mm
Application
Product Construction
Technical Data
Features
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08 White - 09 Orange - 10 Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14 LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19 Purple - 20
Pink - 21
www.siechem.com15
0
ü
Temperature Range : +105 C
ü
Rated Voltage : 600 V AC
417
Catalogue
No
18
16
14
12
10
1.52
1.52
1.52
1.52
1.52
4.24
4.57
4.95
5.44
6.15
26.32
33.22
42.85
57.38
80.83
ü
Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü
Insulation : PVC
ü
Colour : As per customer order.
41781XX
41780XX
41779XX
41778XX
41777XX
0
Siechem UL 1275 APC, PVC Insulated 105 C, 600 V AC Cable
21.8
13.7
8.59
5.41
3.41
16/0.254
26/0.254
41/0.254
65/0.254
105/0.254
Max.
Conductor
Resistance
0
at 20 C
Ω/km
ü
Appliance wiring
ü
Internal wiring of meters, panels, electrical
and electronic equipment.
ü
Flame retardant
ü
Resistant to water, oil, acids, solvents
and fungus.
