Siechem
UL 1569 RoHS
Wires & Cables
Application
Product Construction
Technical Data
Features
www.siechem.comConductor
Size
No. of
Strands /
Wire dia
Conductor Construction
Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG
nos. / mm
mm
kg/km
mm
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08 White - 09 Orange - 10 Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14 LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19 Purple - 20
Pink - 21
420
Catalogue
No
24
22
20
18
16
14
12
10
18
16
1.42
1.60
1.76
2.00
2.33
2.71
3.20
3.91
1.82
2.09
3.89
5.47
7.14
10.38
15.62
23.28
35.31
55.15
9.91
14.71
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
0.40
18
0
ü
Temperature Range : +105 C
ü
Voltage Rating : 300 V AC
ü
Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü
Insulation : PVC
ü
Optional PVC Covering
ü
Colour : As per customer order.
42084XX
42083XX
42082XX
42081XX
42080XX
42079XX
42078XX
42077XX
S42081XX
S42080XX
0
Siechem UL 1569 APC, PVC Insulated 105 C, 300V AC Cable
87.6
55.4
34.8
21.8
13.7
8.59
5.41
3.41
21.4
13.5
7/0.193
7/0.254
10/0.254
16/0.254
26/0.254
41/0.254
65/0.254
105/0.254
1/1.024
1/1.294
Max.
Conductor
Resistance
0
at 20 C
Ω/km
ü
Appliance wiring
ü
Internal wiring of meters, panels, electrical
and electronic equipment.
ü
Flame retardant
ü
Resistant to water, oil, acids, solvents
and fungus.
OHSAS
18001
ISO
9001
ISO
14001
