Siechem
UL 1284 RoHS
Wires & Cables
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction
Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG
nos. / mm
mm
kg/km
mm
Application
Product Construction
Technical Data
Features
Note : XX* : Please add last two digits in the part number as per the colour code given hereunder replacing XX while ordering.
Red - 01 Yellow - 02
Blue - 03
Black - 04
Green - 05 Yellow-Green - 06 Grey - 07
Brown - 08 White - 09 Orange - 10 Violet - 11
Chocolate - 12
Tan - 13
Charcoal - 14 LT Blue - 15 DK Grey - 16 LT Green - 17 DK Green - 18 DK Blue - 19 Purple - 20
Pink - 21
www.siechem.com419
Catalogue
No
8
6
4
2
1
1/0
2/0
3/0
4/0
2.03
2.03
2.03
2.03
2.03
2.03
2.03
2.03
2.03
8.17
9.18
10.47
11.98
12.93
14.10
15.30
16.67
18.19
136.41
191.58
276.96
397.97
486.49
597.63
733.13
905.70
1119.57
17
0
ü
Temperature Range : +105 C
ü
Rated Voltage : 600 V AC
ü
Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü
Insulation : PVC
ü
Colour : As per customer order.
41976XX
41975XX
41974XX
41973XX
41972XX
41990XX
41991XX
41992XX
41994XX
0
Siechem UL 1284 APC, PVC Insulated 105 C, 600 V AC Cable
2.18
1.38
0.865
0.547
0.434
0.344
0.272
0.216
0.171
168/0.254
266/ 0.254
133/ 0.455
259/ 0.405
259/0.455
259/ 0.511
259/0.573
259/0.644
259/0.723
Max.
Conductor
Resistance
0
at 20 C
Ω/km
ü
Appliance wiring
ü
Internal wiring of meters, panels, electrical
and electronic equipment.
ü
Flame retardant
ü
Resistant to water, oil, acids, solvents
and fungus.
OHSAS
18001
