UL CDR FILE

31 / 46

Siechem UL 2587 RoHS
Wires & Cables
Application Product Construction Technical Data
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction Cable
Overall
Diameter Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG nos. / mm mm kg/km mm
431
Catalogue
No
16
16
16
16
16
16
16
16
16
16
16
14
14
14
14
12
12
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.297
19/0.373
19/0.373
19/0.373
19/0.373
19/0.47
19/0.47
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.55
0.8
0.8
0.8
0.8
0.8
0.8
30
0
ü Temperature Range : +90 C
ü Voltage Rating : 600 V AC
ü Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü Insulation : PVC
ü Optional covering, shield
ü Jacket : PVC
ü Colour : As per customer order.
4318002
4318002
4318002
4318002
4318002
4318002
4318002
4318002
4318002
4318002
4318002
4317902
4317902
4317902
4317902
4317802
4317802
0 Siechem UL 2587 APC, PVC Insulated 90 C, 600 V AC Cable
Number
of Cores
Outer Sheath
Thickness
Nom.
Nos. mm
2
3
4
5
7
8
9
12
15
19
25
2
4
5
7
2
4
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
6.80
7.22
7.90
8.62
9.41
10.58
11.49
12.42
13.83
14.61
17.21
8.57
10.04
11.01
12.06
9.55
11.22
71.37
87.60
104.52
132.97
163.55
193.14
220.29
276.06
341.24
410.20
545.48
112.67
166.19
213.96
263.39
150.02
227.31
13.7
13.7
13.7
13.7
13.7
13.7
13.7
13.7
13.7
13.7
13.7
8.62
8.62
8.62
8.62
5.43
5.43
Max.
Conductor
Resistance
0 at 20 C
Ω/km
Features
ü Appliance wiring
ü Internal wiring of meters, panels, electrical
and electronic equipment.
ü Flame retardant
ü Resistant to water, oil, acids, solvents
and fungus.
