UL CDR FILE

27 / 46

Siechem UL 2129 RoHS
Wires & Cables
Application Product Construction Technical Data
Features
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG nos. / mm mm kg/km mm
Outer Sheath
Thickness
Nom.
mm
24
22
20
18
16
18
16
12
12
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.61
0.61
7.62
8.01
8.38
8.98
9.77
8.60
9.24
9.23
10.91
76.62
89.80
101.17
121.86
153.23
116.06
144.16
312.33
357.10
428
Catalogue
No
26
0
ü Temperature Range : +105 C
ü Voltage Rating : 1000 V AC
ü Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü Insulation : PVC
ü Optional Shield
ü Jacket : PVC
ü Colour : As per customer order.
0 Siechem UL 2129 APC, PVC Insulated 105 C, 1000 V AC Cable
4288402
4288302
4288202
4288102
4288002
S4288102
S4288002
4287802
4287802
87.6
55.4
34.8
21.8
13.7
21.4
13.5
5.43
5.43
7/0.193
7/0.254
10/0.254
16/0.254
26/0.254
1/1.024
1/1.291
19/0.47
19/0.47
Max.
Conductor
Resistance
0 at 20 C
Ω/km
ü Appliance wiring
ü Internal wiring of meters, panels, electrical
and electronic equipment.
ü Flame retardant
ü Resistant to water, oil, acids, solvents
and fungus.
