UL CDR FILE

26 / 46

Siechem UL 2128 RoHS
Wires & Cables
Application Product Construction Technical Data
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG nos. / mm mm kg/km mm
Outer Sheath
Thickness
Nom.
mm
24
22
20
18
16
12
12
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.8
0.61
0.61
7.04
7.39
7.72
8.25
8.96
9.23
10.91
67.73
78.89
88.35
105.46
131.21
312.33
357.10
427
Catalogue
No
25
0
ü Temperature Range : +105 C
ü Voltage Rating : 600 V AC
ü Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü Insulation : PVC
ü Optional Shield
ü Jacket : PVC
ü Colour : As per customer order.
4278403
4278303
4278203
4278103
4278003
4277803
4277803
0 Siechem UL 2128 APC, PVC Insulated 105 C, 600 V AC Cable
87.6
55.4
34.8
21.8
13.7
5.43
5.43
7 / 0.193
7 / 0.254
10 / 0.254
16 / 0.254
26 / 0.254
19 / 0.47
19 / 0.47
Max.
Conductor
Resistance
0 at 20 C
Ω/km
Features
ü Appliance wiring
ü Internal wiring of meters, panels, electrical
and electronic equipment.
ü Flame retardant
ü Resistant to water, oil, acids, solvents
and fungus.
