UL CDR FILE

25 / 46

Siechem UL 2127 RoHS
Wires & Cables
Application Product Construction Technical Data
Conductor
Size
No. of
Strands /
Wire dia
Conductor Construction Cable
Overall
Diameter
Weight
Approx.
Max.
Insulation
Wall Thickness
Nom.
Part
Number
AWG nos. / mm mm kg/km mm
Outer Sheath
Thickness
Nom.
mm
426
Catalogue
No
24
22
20
18
16
12
12
0.8
0.8
0.8
0.8
0.8
0.8
0.8
6.68
7.01
7.31
7.91
8.56
9.23
10.91
60.09
69.41
77.04
92.53
112.96
312.33
357.10
0.8
0.8
0.8
0.8
0.8
0.61
0.61
24
0
ü Temperature Range : +105 C
ü Voltage Rating : 600 V AC
ü Conductor : Annealed Solid / Stranded Bare Copper
(Tinning on request)
ü Insulation : PVC
ü Optional Shield
ü Jacket : PVC
ü Colour : As per customer order.
4268402
4268302
4268202
4268102
4268002
4267802
4267802
0 Siechem UL 2127 APC, PVC Insulated 105 C, 600 V AC Cable
87.6
55.4
34.8
21.8
13.7
5.43
5.43
Max.
Conductor
Resistance
0 at 20 C
Ω/km
7/0.193
7/0.254
10/0.254
16/0.254
26/0.254
19/0.47
19/0.47
Features
ü Appliance wiring
ü Internal wiring of meters, panels, electrical
and electronic equipment.
ü Flame retardant
ü Resistant to water, oil, acids, solvents
and fungus.
